M9 concept sketch

Recommended Posts

Advertisement (gone after registration)

Here is a sketch I made for a possible M9. Don't look too closely at my PS skills. It's only sketch.



I eliminated the step on the top plate and moved the shutter speed dial to the rear (thumb operated). The shutter speed dial would be recessed in to the body and reside under the top plate. It could even be spring loaded as an additional switch (depress for AE lock?).



My reason for wanting to eliminate the step was to free up more internal space for electronics. With the advance lever gone, there is no real reason for it.



Obviously this is a controversial suggestion, but I'm not married to the idea of eliminating it. There is something nice about that big shutter speed dial on top of the M8 and I would have to handle a mock up to see how it affects the operation of the shutter release...



Regardless of the top plate I have a few other ideas that I believe would make the camera more useable.





- I added an AE-L lock button. This way you can take multiple shots with the same meter reading. I would love to have a button like this on my M7...



An alternative idea is that AE-L lock could be triggered by depressing the shutter speed dial, when it is set to A (aperture priority) mode. Choosing that solution would eliminate the need for a separate AE-L button.



- Also added easy to operate -/+ buttons for exposure compensation.



- On/Off/Continuous lever moved to the rear panel, since with the step eliminated there is no room on the top plate for it.



The rear positioned shutter speed dial, AE-L and exposure compensation buttons can all be operate by your thumb, without taking your eye from the viewfinder.



OLED on the top plate, like the S2, showing shutter speed etc.



Also added a concept for a heavy duty battery pack that attaches to the bottom of the camera. It should be similar in size to a Leicavit. The pack should hold two standard M8 batteries. This could result in a total of up to three batteries powering the camera at once.



Flame away.
