mike prevette

Proof of concept regarding self coding of lenses

Recommended Posts

Advertisement (gone after registration)

/applications/core/interface/imageproxy/imageproxy.php?img=http://static.flickr.com/118/309102421_6683080fe1_o.jpg&key=ae55062a8eb94117b1b59c875a71d5fb82d8afbaa906ad500e63930403d99178">





With nothing more than a sharpie I was able to trick my M8 into thinking my Zeiss 21 was really a 50mm Leica lens. Of course this isnt for any practical purpose except to prove it's possible with little or no tools.



_mike

Flickr: Photos from mike@freedomfromgravity

Share this post


Link to post
Share on other sites
Well done!



All we need is a database of the various codes.

I was keeping track of Mark Nortons's scans of the codings, for a while and the 21mm Elmar Asph was 000XX0. Mark or others can verify.

Bob

Share this post


Link to post
Share on other sites
A Sharpie... LOL!

BTW if anyone does come up with a list of codes, I'll gladly add it to the M8 FAQ topic at:

Leica FAQ - Leica M8 Digital



Well we could start by just sending in codes of lenses we own! I'll send in my 35mm Sumicron code later this evening (morning your time).



- Vikas

Share this post


Link to post
Share on other sites

Wonderful! Must try that on my 50mm!



Incidentally, any reason for masking "M8" and the red dot?!



- Vikas

Share this post


Link to post
Share on other sites

Advertisement (gone after registration)

Wonderful! Must try that on my 50mm!



Incidentally, any reason for masking "M8" and the red dot?!



- Vikas



Street precaution – less attraction...

I've done plenty of shots in the street (architectural and parks) in rather questionable areas with two M6 and a R6.2 masked. You feel somehow safer this way...



Regards,



Horacio

Share this post


Link to post
Share on other sites

Please keep up the "R&D" on homegrown coding and thanks. If we can find a solution that's more than temporary, it would be very helpful to a lot of photographers. I absolutely love it that people are trying to get this one figured out.



Cheers,



Sean

Share this post


Link to post
Share on other sites

Popflash is missing a couple from the current lineup: 90/4 Macro, 90 Elmarit, Apo 90 Cron, 135/3.4, 28 Cron, 75 Lux. Can anyone help out with these codes? I am trying to collect them all.

Share this post


Link to post
Share on other sites
Guest guy_mancuso

Carsten I have the 28mm Cron. Lovely lens and it is coded.



Best way to do this is lens at camera on postion than put face down.

w,b,w,b,b,w



I need the 24mm 2.8 and the 35 1.4 asph. Hell i will try the sharpie. i even have colored ones. LOL

Share this post


Link to post
Share on other sites

Here are the codes from the Popflash photos. 0 = white (no mark with sharpie), X = black, looking at the back of the lens mount in a clockwise direction. Some lenses are missing.



21 f2.8 0XX000

24 f2.8 0XX00X

TE f4.0 X0X0X0

28 f2.8 0XXX00

35 f1.4 0XXX0X

35 f2.0 0XXXX0

50 f1.0 0XXXXX

50 f1.4 X00000

50 f2.0 X0000X

50 f2.8 X000X0

75 f2.0 X00X00

90 f2.0 0XXX0X



How many Sharpies can you buy for $125?



Stan

Share this post


Link to post
Share on other sites

I suspect this thread will be quickly locked down or simply disappear because it's obviously offending the forum sponsor's business interest.

Share this post


Link to post
Share on other sites
I suspect this thread will be quickly locked down or simply disappear because it's obviously offending the forum sponsor's business interest.



I doubt it. I would argue that it's in Leica's best interests to have this camera work with various lenses without needing to have them sent in for coding. I won't repeat my argument against a "closed system" for the M8 because I've explained it in other threads but I think that neither Leica nor the customer is well served by a closed system.



Sean

Share this post


Link to post
Share on other sites
Guest guy_mancuso

Darn i tried the 24mm but i did it by sight , i will try again tomorrow. The nice thing is the sharpie comes off if you mess up

Share this post


Link to post
Share on other sites
Here are the codes from the Popflash photos.

35 f1.4 0XXX00



i don't think this is correct for the latest ASPH model (4th gen?)



working clockwise, it would be 0XXX0X



most of the others in this thread are counter-clockwise. we should standardize.

Share this post


Link to post
Share on other sites
